Abstract
The plans for the 3-blade, 730 mm (0.73 m), TSR 7 turbine can be purchased as a pdf document and are included with every purchase. The blade used in the 500 W page is the same as the one shown in these schematics and uses an inverse airfoil design (spin in the reverse direction), giving equal efficiency to the standard design.
Keywords: Wind turbine plans, Wind turbine Schematics, Wind turbine construction, Inverse airfoil design.
Preview Page: 500 W Turbine Plans

Materials, Plans and Schematics for 3-Blades
730 mm (0.73 m), TSR 7

LIST OF FIGURES
Figure 2. Pages 3 and 4;

Airfoil chord section stencils for the 3-bladed, 730 mm, TSR 7 turbine (left) and dimensions for the hub and angle guide (right)

.
A high resolution PDF version is included free with any purchase of the ‘Wind Turbine PDF plans’
Title Page
Figure 1: Pages 1 and 2;

Materials and outlay cover page (left). A diagram for the layout of chord cross-section stencils and the hub (right)

.
Figure 3: Pages 5 and 6;

Stencils for the angle guide and dimensions for the skeleton root.

Perspective and Layout
Construction approach
Cross-section stencils
Root shape and properties
Airfoil positioning

500 W Plans Preview

Frequently asked questions about plan orders, blade design, electrical work and generator matching can be found on our Q&A pages.
